750 W
Power draw, up to
IP65
EXOclaws™ enclosure
60 + 11
Strobe and wash sections
2 years
Warranty
Features
Hybrid strobe/wash
Engineered for the Visual Freaks — a hybrid strobe/wash fixture that disrupts the flat, predictable rectangular strobe bar convention.
LIQUIDshine™ wash
RGBW engine, 400W, split into 11 controllable sections — uses a mirrored chamber to turn the color output into a layered, liquid-like glow.
TRI-X™ strobe
700W cool white, split into 60 pixel-controllable sections across three X-shaped strobe heads — built to punch through heavy haze.
Outdoor-rated
IP65 — housed in the EXOclaws™ enclosure for outdoor-rated durability.
Flexible control
DMX512 and RDM, with CRMX wireless available as an option. 7 selectable DMX personalities (8 to 220 channels), master/follower linking and built-in macros.
Colour Feedback System™
Automatic status reporting, with an onboard OLED screen.
Two light engines
Let's strobe crazy! One fixture, a liquid-like RGBW wash and a haze-piercing cool white strobe.
Output
Wash: ~7,874 lumens, 81° beam angle
Strobe: ~23,541 lumens, 111° beam angle
See FREAX in Action
Technical specification
Dimensions
54 x 15 x 19 cm / 21.3 x 8.1 x 7.4 in
Weight (fixture only)
12 kg (about 26.5 lbs)
Input voltage
100-240 V, 50/60 Hz
Power draw
Up to 750 W
Power connector
PowerCon TRUE1, in/thru
Light engines
Wash: LIQUIDshine™ RGBW engine, 400W, 11 controllable sections | Strobe: TRI-X™, 700W cool white, 60 pixel-controllable sections across three X-shaped strobe heads
Beam angle
81° (wash) | 111° (strobe)
Color temperature
3000K plus RGB mixing (wash) | 6500K (strobe)
Output (total luminous flux)
~7,874 lumens (wash) | ~23,541 lumens (strobe)
CRI
85 (wash) | 70 (strobe)
Control ports
DMX512, RDM, CRMX wireless available as an option
Control features
7 selectable DMX personalities (8 to 220 channels) | Master/follower linking | Built-in macros | Colour Feedback System™
Display
Onboard OLED screen
Ingress protection
IP65 — EXOclaws™ enclosure
What's in the box
Fixture, AC power cable (PowerCon TRUE1, plug not included), User manual | CE | 2 years warranty
